Made a new tool

[eskimomann209]

Sliding glass door rollers?

Tubing straightener.

I’m pretty sure he was asking what the rollers were sourced from,
no?



[dvdswan]

Pretty simple and effective. Nicely done.



[SquareRoot]

After rolling it out on the ground, you can clamp one end in a vice and the other end in a pair of vice grips. Then bend the vice grip end at a right angle, the hit the vice grip with a mini sledge. Makes it as straight as an arrow.

I've heard that straightening brake line in this manner can create untraceable harmonic vibrations in the driveline/suspension.



[Mr Clean]

Sliding glass door rollers?

Yes sir, my hardware store called the patio door rollers, but the same thing.



[Catbox]

Nice work.
I will have to remember this method for when I need to make things straight.



[Mr Clean]

Nice work.
I will have to remember this method for when I need to make things straight.

Thanks...I just couldn't see spending 100 bucks or more on something that doesn't get used all the time, and it is only for one thing.



[Ricko1966]

You must be registered for see images attach

10.00 brake pressure bleeder. The pressure part is a 6.00 Dollar General plant sprayer. The clear tubing came from the hardware store..The pressure cap is a piece of scrap aluminum plate with a hole drilled and tapped for a barbed fitting.I glued a piece of rubber to the other side and clamp it down with strap iron, all thread and old exhaust springs.



[Ricko1966]

You must be registered for see images attach

A piece of solder and 2 alligator clips to hold wires while you solder.



[Ricko1966]

You must be registered for see images attach

A bearing separator, some all thread a hyraulic jack. I pull crank gears, bearing races etc. Put the jaws together and it's a little press

You must be registered for see images attach



[Ricko1966]

You must be registered for see images attach

2 tools here. A piece of steel rod I had laying around and a piece of scrap strap is brake pedal depressor.The second is a piece of plate with a hole with a socket through it and welded.You put your breaker bar in the socket and put pressure on it smack the plate clockwise or counter clockwise with a hammer, for that really tight stuff.



[78C10BigTen]

You must be registered for see images attach

A bearing separator, some all thread a hyraulic jack. I pull crank gears, bearing races etc. Put the jaws together and it's a little press

You must be registered for see images attach

I used something similar to pull the front pump outta my th350!



[Ricko1966]

A piece of square tubing a scrap of flat plate, and a tire machine duckhead.Because the junk mount bars they send with the manual tire machines won't pull a tire on and I don't like prying them on. IT'S SOMEBODY ELSES TURN!!

You must be registered for see images attach



[Ricko1966]

A 13 piece bearing race and seal installer, that you can take off nuts and bolts too. Okay I don't really have those, or any harbor frieght sockets.but I do use my sockets for driving in seals and races I just don't have a pic of my sockets handy.

You must be registered for see images attach



[Turbo4whl]

Tool for holding the drive yoke on the rear axle. Axle in the vehicle, lay it across the leaf spring. Very handy for crushing the collar.

You must be registered for see images attach



[Ricko1966]

Okay, not mine. I have a press and my bearing separator press, But I like this probably will make one for ball joints and U joints. Yes I have the big c clamp service press but think this will be more useful.

You must be registered for see images attach
