Replacing front brake lines - remove proportioning valve?

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

tophat36

Full Access Member
Joined
Aug 5, 2022
Posts
86
Reaction score
112
Location
Bremerton, WA
First Name
Jessica
Truck Year
1980
Truck Model
C2500
Engine Size
350-4 V8
I really want to replace the front brake lines and hoses but as it goes for everyone, been a real bitch to get the flare fittings loose on the lines and at the proportioning valve. No issue getting the lines loosening on master cylinder. My question is, if I unbolt the proportioning valve or partially unbolt/loosen, will this make it easier? Only line I don’t have yet that attaches to the valve is the front to rear line. I could potentially just cut the others, but can’t mess that one up. Any thoughts or suggestions on this? The access to these fittings is pretty stupid. I can grab my crows feet from work but until then I’m trying to be creative. I guess I could buy line wrench crows feet, I think that exists. I can’t get a dang vice grip on the inside/tube side. Nothing seems to be working and I’m loosing faith :(


Old Guy Bill

Full Access Member
Joined
Sep 10, 2023
Posts
319
Reaction score
922
Location
KY
First Name
Bill
Truck Year
1978
Truck Model
K20
Engine Size
400
There are different sizes/styles of vise grips…
When you get ready to put it back together some Anti-Sieze on the threads of the fittings will prevent it from happening again.
You must be registered for see images attach


legopnuematic

Licensed Junk Dealer
Supporting Member
Joined
Oct 27, 2016
Posts
1,977
Reaction score
4,448
Location
MO
First Name
Spencer
Truck Year
1971, 1̶9̶7̶4, 1976, 1979,1̶9̶8̶5, 2002
Truck Model
Dart Swinger, Sierra 10, C10 Cheyenne, C10 Big Ten, Silverado 10, Ram 2500
Engine Size
225/6, 350 c.i., 350 c.i., 5.9l Cummins
They exist.
You must be registered for see images attach


Have you tried a regular flare wrench?

If you have a flaring tool, you may be time ahead by just cutting the line, then cut it back a foot or two (wherever is most convenient), flare, and install a union (not a compression fitting). Bend a new line to prop valve.


legopnuematic

Licensed Junk Dealer
Supporting Member
Joined
Oct 27, 2016
Posts
1,977
Reaction score
4,448
Location
MO
First Name
Spencer
Truck Year
1971, 1̶9̶7̶4, 1976, 1979,1̶9̶8̶5, 2002
Truck Model
Dart Swinger, Sierra 10, C10 Cheyenne, C10 Big Ten, Silverado 10, Ram 2500
Engine Size
225/6, 350 c.i., 350 c.i., 5.9l Cummins
Those Sunex flare crows-foot wrenches are on sale on Amazon for $12 for the set currently.

Here

I’ve got both the standard and metric sets, I’ve been pleased with them so far.
