help!!!!!!!

[Brandon_l1000]

ok guys i am rewiring my rear light it was hack job my problem is i can get all my lights on at the same time but when i hit my brake lights my left turn signal wont come on, and the indicator on the dash stays lite up. ok my question is where do the wire coming off of the brake light switch run i know one runs to the fuse box where does the other one go?



[Brandon_l1000]

nevermind figured it out i had ran a new wire to the brake lights from the switch that was my problem the other wire runs to the turn signal switch i guess when you turn the turn signal on it cancels the brake light to that bulb or something but it works thats all i care about lol.



[89Suburban]

Ooo!! Oooo!!
