Never mind, I see you have some sort of seal there in later photos.
Good observation. When I first assembled I had not put the shroud seal in, but installed it later when I got to doing final assembly. The seal is epoxied to the shroud and touches the radiator. So far I have had zero overheating issues. The electric fan thermostat is 180 degree on, which is too cool. I have a new switch which is 200 on, that I have not yet installed.

So far I am very happy with the performance of the cooling system. I have lots of highway driving including long steep uphill grades. I've also had my fair share of diabolical Southern California stop and go traffic, and it never gets hot. I am yet to take it off road for an extended period. The off road is the ultimate test for cooling.


grampsbutler

Full Access Member
Joined
Oct 3, 2021
Posts
56
Reaction score
226
Location
San Diego, CA
First Name
Graham
Truck Year
1984
Truck Model
K10 Suburban
Engine Size
6.2l Diesel
Update: I took some time off from working on the truck last month. We went on a 1000 mile trip up to the mountains for a week of winter sports fun. The truck ran very well except for 2 things.

1: Problems cold starting: We had a pretty good storm dump a foot of snow on us and pull temps down to ~10 degrees Fahrenheit (that's -12c). Truck would not start, and I had to get a jump. Lesson learned: These trucks need dual batteries to handle cold weather. I only had a single battery installed. It started on the first turn every time over 20 degrees (grid heater is not connected). Parts for the second battery are on order.

2: Dead Pedal: If you've been following along, you'll know that I have been battling intermittent dead pedal. I thought I had it solved after cleaning my ground connections, rebuilding the body wiring harness and replacing the Accelerator pedal. Truck ran all week with no issues, but on the way home I lost accelerator several times. I ran through the accelerator recalibration procedure when I got home, and it seems to have cured the problem....at least for the time being.

The dead pedal has been the most persistent and frustrating problem with this build. My next step will be to replace the the ECU.

You must be registered for see images attach


You must be registered for see images attach


You must be registered for see images attach
You must be registered for see images attach


mcarlo86

Full Access Member
Joined
May 17, 2019
Posts
534
Reaction score
933
Location
ND
First Name
Brian
Truck Year
1990
Truck Model
Suburban
Engine Size
350
Update: I took some time off from working on the truck last month. We went on a 1000 mile trip up to the mountains for a week of winter sports fun. The truck ran very well except for 2 things.

1: Problems cold starting: We had a pretty good storm dump a foot of snow on us and pull temps down to ~10 degrees Fahrenheit (that's -12c). Truck would not start, and I had to get a jump. Lesson learned: These trucks need dual batteries to handle cold weather. I only had a single battery installed. It started on the first turn every time over 20 degrees (grid heater is not connected). Parts for the second battery are on order.

2: Dead Pedal: If you've been following along, you'll know that I have been battling intermittent dead pedal. I thought I had it solved after cleaning my ground connections, rebuilding the body wiring harness and replacing the Accelerator pedal. Truck ran all week with no issues, but on the way home I lost accelerator several times. I ran through the accelerator recalibration procedure when I got home, and it seems to have cured the problem....at least for the time being.

The dead pedal has been the most persistent and frustrating problem with this build. My next step will be to replace the the ECU.

You must be registered for see images attach


You must be registered for see images attach


You must be registered for see images attach
You must be registered for see images attach
Why is the grid heater not hooked up? That really helps too for cold starting.


grampsbutler

Full Access Member
Joined
Oct 3, 2021
Posts
56
Reaction score
226
Location
San Diego, CA
First Name
Graham
Truck Year
1984
Truck Model
K10 Suburban
Engine Size
6.2l Diesel
Front Axle: I put some time in to regearing the front D60. The axle came with 4.10 gears, but the truck is 3.73. I am very happy with the 3.73 ratio. I can run on the highway at 75 mph at approximately 2000 rpms and 1600 at 65mph. I have never felt like it was geared too high.

I got a gearset and master rebuild kit from Motive Gear, and I ordered a new carrier from Ox Locker. I ordered a D60 carrier bearing puller (linked). I went with the Ox locker because I like the simplicity of a mechanical system.

Before I started the teardown, I measured the backlash to be 10 thousandths. I pulled the old bearings and took careful notes of the shim pack measurements. I put the new bearings on the new carrier with the shim packs measuring the same as the original. First time out the gate the gears were binding - Zero backlash. I pulled it all apart and moved shims to move the crown gear away from the pinion. This time I was able to run a gear pattern and found that contact was too far to the tip of the gear. So I increased pinion depth, and adjusted the preload to be approx 25 in lbs. It ran another gear pattern, and it was much improved centering on the tooth, but the backlash was coming in at 18 thousandths. Final adjustment I adjusted shims by 0.018, reassembled and got to 0.006 of backlash. I am happy with this because they are new gears and should wear in to ~0.01".

That is about as far as I got this week next I need to take a look at the U-Joint and see whether I need to replace it to match the front drive shaft. Then it is diff cover and axle reinstallation.

Final Pattern
You must be registered for see images attach


First pattern
You must be registered for see images attach


grampsbutler

Full Access Member
Joined
Oct 3, 2021
Posts
56
Reaction score
226
Location
San Diego, CA
First Name
Graham
Truck Year
1984
Truck Model
K10 Suburban
Engine Size
6.2l Diesel
Why is the grid heater not hooked up? That really helps too for cold starting.

I just haven't had time to figure out how the grid heater should be wired up and whether it should be controlled by the ECU. The symptom was a dead battery. It wouldn't even turn the engine over, so the grid heater wouldn't have helped me in this case........as soon as I had a jump start it fired right up.

To make sure that this doesn't happen again, I did install a second battery this weekend. I placed it in the cargo area over the rear wheel, and ran heavy cable to the back. I will figure out the grid heater before next winter, but it really will only get used when I go up to elevation. Where I live it never gets below freezing.

You must be registered for see images attach

You must be registered for see images attach
You must be registered for see images attach


1lejohn

Full Access Member
Joined
May 14, 2012
Posts
240
Reaction score
501
Location
texas
First Name
john
Truck Year
1985 , 2004
Truck Model
k-1500, 2500 HD
Engine Size
350, 6.7
Where did you order the wiring blocks for the battery posts? Those are awesome .


NHsquare

Junior Member
Joined
Jun 12, 2024
Posts
2
Reaction score
2
Location
New Hampshire
First Name
Nick
Truck Year
1987
Truck Model
C30
Engine Size
454
Thrilled to see someone has accomplished what I am in the process of setting out to do, even if you are clear on the other side of the country! Rolling through your posts have answered a few of the questions I had rolling in my head about my own swap, how have you liked the dakota gauges running them on the obd connector? Have you had any thoughts for how you're going to get speed signal to the dash?

Also a thought on your dead pedal situation, the pedal circuit is EXTREMELY sensitive to any breaks or increase in resistance over factory on the common rail cummins, how did you run that wire from the OEM connector to the pedal in the cab? Your ecm may be seeing a variance between apps 1 and apps 2 circuits and assuming there is a failure, hence the dead pedal.
