1985 c10 step side 4speed manual transmission exploded view

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

siataspring850

Junior Member
Joined
Nov 23, 2022
Posts
12
Reaction score
0
Location
delaware
First Name
mike
Truck Year
1985
Truck Model
c/10 step side
Engine Size
4.3
Newbie
I just bought a 1985 c10 it has the 3 speed OD (4 speed) in it. I think it is stuck in OD. 1st and 2nd are so long it's hard to believe that's normal. I have only driven it home and around the hood. I had to put power steering on it to make it user friendly. With the wide tires it was a bear to drive with a manual steering box.
Now the next issue is to figure out this tranny and its solenoid. I can't seem to find much out about it. Does anyone have an exploded view diagram of the tranny? hate to pull the thing it is getting cold out there and I am getting old...the two don't mix well


Attachments

  • thumbnail_PXL_20221101_175121313.jpg
    271.6 KB · Views: 48
Last edited:

Keith Seymore

Full Access Member
Joined
Jul 13, 2015
Posts
2,635
Reaction score
8,106
Location
Motor City
First Name
Keith Seymore
Truck Year
1987
Truck Model
R10
Engine Size
4.3L
When you say "1st and 2nd are so long" do you mean the gear ratios? Or the amount the lever moves when shifting?

It's a pretty long throw when changing gears. A deeper first gear (higher numerical ratio) would be nice, especially to help get rolling when trailering.

As far as finding an exploded diagram you will want to search for "MY6 New Process A833" trans info.

K
You must be registered for see images attach


siataspring850

Junior Member
Joined
Nov 23, 2022
Posts
12
Reaction score
0
Location
delaware
First Name
mike
Truck Year
1985
Truck Model
c/10 step side
Engine Size
4.3
thank you
I mean I don't have to shift out of 1st gear for awhile
I will hook up the speedometer later on today.feels like 30 to 35 mph. I would think I would have to shift sooner. I need to prove out the rear end final drive ratio before I go nuts over it. I just got the truck so I need to figure it out


siataspring850

Junior Member
Joined
Nov 23, 2022
Posts
12
Reaction score
0
Location
delaware
First Name
mike
Truck Year
1985
Truck Model
c/10 step side
Engine Size
4.3
I read some where 1st gear ratio is 1.9


siataspring850

Junior Member
Joined
Nov 23, 2022
Posts
12
Reaction score
0
Location
delaware
First Name
mike
Truck Year
1985
Truck Model
c/10 step side
Engine Size
4.3
looks like the rear ratio is a 3.08
explains a lot . with the aftermarket wheels and tires no need for OD. it just dog's out the engine.
I'm going to have to change the rear or the transmission to make it more drivable


Keith Seymore

Full Access Member
Joined
Jul 13, 2015
Posts
2,635
Reaction score
8,106
Location
Motor City
First Name
Keith Seymore
Truck Year
1987
Truck Model
R10
Engine Size
4.3L
Yes - 3.73 is a nice choice.

That is the equivalent of a 3.42 gear without overdrive.

K
