Hey guys,
I have searched and searched before I get flamed. :sorry:

I can't seem to find the automatic hub parts break down. I went to replace a front caliper and there was a ton of slop in the hub. So, for the first time ever, I tore down the automatic hubs. I have a snap ring left over and another part. I think the owner before me took this hub apart before. I only say that because the first shaft nut i took off had/has no little knob for the next middle washer thing with all the holes to Lock the initial axle nut.

Also, the axle nub that comes through the spindle has a lot of play in it. Is this normal or are there/is a bearing in spindle half?

Any and all help is greatly appreciated ahead of time.


Attachments

  • 12928337_10154120886535990_2915558433471213180_n.jpg
    80.3 KB · Views: 144

jetman

Full Access Member
Joined
Dec 26, 2012
Posts
213
Reaction score
11
Location
Minnie, AK
First Name
Don
Truck Year
1980
Truck Model
c10
Engine Size
5.0
Sent the Auto Hub info from GM shop manual to website: http://www.bacliffrv.com/TruckParts/index.html .

Some people like em, I prefer manual hubs since I quite often use 4L to obtain 2W granny gear to shove around heavy trailers on hard surface.

Last edited:

1986ChrisK10

Full Access Member
Joined
Mar 20, 2016
Posts
73
Reaction score
0
Location
Mississippi
First Name
Chris
Truck Year
1986
Truck Model
K10
Engine Size
350
Jetman I have to say your awesome! Sorry for the late reply seems I forgot to turn the notifications on for this thread. That is exactly what I was looking for. Maybe somebody searching will find this as well.

Again Thanks

*heres a cyber beer of your choice*


1986ChrisK10

Full Access Member
Joined
Mar 20, 2016
Posts
73
Reaction score
0
Location
Mississippi
First Name
Chris
Truck Year
1986
Truck Model
K10
Engine Size
350
Question incase anybody may know.

#28 Snap ring, I think is what is my "extra piece" I did notice two grooves to the start of the axle nub, but if I am reading the schemadic correctly, it looks to be closer to the wheel bearings ride/sit.

Can anybody clarify this? My other missing unknown piece is the space #27 I think. It is more like a washer but cupped to one side. Any idea which way it should face?

Sorry for the noob question, I have never messed with SFA's till now and I really don't believe the truck was put together incorrectly by PO.
